Overview
These elements are made of high-strength aluminium alloy.
The fixing clamp is designed for single anchoring whereas the bracket offers up to 6 fixing points.
Their specific design allows fixing on wooden, metal or concrete poles.
The fixing clamp is implemented using a 10mm diameter bolt or a 20x0.7mm stainless steel strap (tensile strength: 200daN).
The ABC cable pole bracket is implemented using a 14 or 16-mm diameter bolt or using two 20x0.7mm stainless steel straps (tensile strength: 200daN/anchoring point).
This anchoring assembly meets the criteria of the NF C 33-042 and EN 50-483 standards
Characteristics:
Made from high-strength galvanized steel for durability.
Designed to withstand high mechanical loads and environmental stress.
Easy to install and provides stable anchoring for various cable types.
Anchoring bracket hook is used with bands in pole installation
These elements are made of high-strength aluminium alloy.
The fixing clamp is designed for single anchoring whereas the bracket offers up to 6 fixing points.
Their specific design allows fixing on wooden, metal or concrete poles.
The fixing clamp is implemented using a 10mm diameter bolt or a 20x0.7mm stainless steel strap (tensile strength: 200daN).
The ABC cable pole bracket is implemented using a 14 or 16-mm diameter bolt or using two 20x0.7mm stainless steel straps (tensile strength: 200daN/anchoring point).
This anchoring assembly meets the criteria of the NF C 33-042 and EN 50-483 standards
Characteristics:
Made from high-strength galvanized steel for durability.
Designed to withstand high mechanical loads and environmental stress.
Easy to install and provides stable anchoring for various cable types.
Anchoring bracket hook is used with bands in pole installation
