Overview
Features:
According to NF C 33 042
Easy to open bail permits fixing to brackets and pigtails
Tool free installation with wedges sliding inside the body
Russian Market Used Weather Proof Aluminum Alloy Overhead Cable Clamp For 4 cores ABC cable conductor
Aluminium Preformed Tension clamp for the anchoring of 2-core overhead cables to poles or walls by standard hooks
Tension clamp for the anchoring of 2-core 2x(16-35) mm² overhead cables to poles or walls by standard hooks. Tension clamp is equipped with a spring to make the installation easier.
NES 4 4ore Cable 120mm2 Aluminum Body Galvanized Steel Helical Tension Clamp Hot Dipped Guy Spiral Grip Dead End
Hop Dip Aluminum Body Preformed Guy Grip Dead Tension Clamp Strain Clamp For 4 Cores ABC Cable Conductor 50mm2
Weather Proof Aluminum Alloy Dead End Clamp For 2 Or 4 Cores ABC Cable Conductor
Characteristics:
Made from high-strength aluminum alloy.
Preformed design ensures secure grip and tensioning.
Resistant to corrosion and environmental factors.
Parameter
Aluminium Preformed Tension Clamp For Aerial Bundle Cable Four Cores 35mm2
The aluminum alloy body anchor clamp is suitable for low-voltage ABC cable.Wedge-type anchoring clamps are intended for fastening of aerial bundle cables on trunk lines or their branches. The clamps provide the required tension of the cable over the span length. The clamp made of high strength aluminum alloy which clamp the neutral messenger without damaging the insulation.Features:
According to NF C 33 042
Easy to open bail permits fixing to brackets and pigtails
Tool free installation with wedges sliding inside the body
Russian Market Used Weather Proof Aluminum Alloy Overhead Cable Clamp For 4 cores ABC cable conductor
Aluminium Preformed Tension clamp for the anchoring of 2-core overhead cables to poles or walls by standard hooks
Tension clamp for the anchoring of 2-core 2x(16-35) mm² overhead cables to poles or walls by standard hooks. Tension clamp is equipped with a spring to make the installation easier.
NES 4 4ore Cable 120mm2 Aluminum Body Galvanized Steel Helical Tension Clamp Hot Dipped Guy Spiral Grip Dead End
Hop Dip Aluminum Body Preformed Guy Grip Dead Tension Clamp Strain Clamp For 4 Cores ABC Cable Conductor 50mm2
Hot Dip Galvanized Aluminium Alloy Body Dead End Tension Clamp For Insulated Messenger Neutral
Weather Proof Aluminum Alloy Dead End Clamp For 2 Or 4 Cores ABC Cable Conductor
Characteristics:
Made from high-strength aluminum alloy.
Preformed design ensures secure grip and tensioning.
Resistant to corrosion and environmental factors.
Parameter
| Item No. | Cross section (mm2) | Material | Conductor(mm) | Breaking load |
| ZC157 | 2X(16-35) | Nylon,Steel | 3-6 | 6.5KN |
| ZC158 | 4X(16-35) | Nylon,Steel | 3-6 | 8KN |
| ZC80 | 2X(16-35) | Nylon,Steel | 3-6 | 22KN |
| ZC160 | 2X(16-35) | 4-8 | 6KN | |
| ZC161 | 4X(16-35) | 4-8 | 8KN | |
| NES-50 | 4X(16-50) | 11-14 | 20KN | |
| NES-120 | 4X(50-120) | 14-16 | 30KN | |
| PAT-50H | 4X(16-50) | 11-14 | 20KN | |
| PAT-95H | 4X(70-95) | 14-16 | 30KN | |
| ZCR-50 | 4X(25-50) | 10-12 | 15KN | |
| ZCR-120 | 4X(50-120) | 11-17 | 30KN | |
| ZCD-435 | 4X(16-35) | 4-11 | 15KN |
