This composite cable is tailored for Electric Vehicle (EV) charging point installations, serving both power and data transmission needs. With UV resistance, it's suitable for outdoor use, making it a convenient and efficient solution for EV charging unit installations.
EV POWER + DATA LSZH Cable Structure
| CONDUCTOR | Plain Copper |
| STRANDING | Class 5 |
| INSULATION | XLPE |
| OUTERSHEATH | LSZH |
| OUTERSHEATH COLOUR | Black |
| RATED VOLTAGE | 0.6/1kV |
| CORE IDENTIFICATION | Element A(CAT 6A F/FTP) Blue,White Orange,White Green,White Brown,White |
| Element B(Power Cable) Blue,Brown and Green/Yellow |
|
| MINIMUM BENDING RADIUS | 6xOverall Diameter |
| OPERATING TEMPERATURE | Flex/installation Temperature:-5℃ to+65℃ Static/working Temperature:-20℃ to +80℃ |
| STANDARDS | EIA-TIA 568,IEC 11801,IEC 61156,EN 50173,EN 50288-10-1,IEC 60502-1,IEC 60332-3-24,IEC 60332-1-2 |
EV POWER + DATA LSZH Specification Data
| Number of cores | Nominal cross sectional area of conductor | Element A diameter | Approx overall diameter | Weight | Element B Max. Conductor Resistance |
| 3 | 4 | 8.3 | 15.9 | 340 | 4.95 Ω/km |
| 3 | 6 | 8.3 | 16.9 | 420 | 3.30 Ω/km |
EV POWER+DATA ARMOURED LSZH Cable Structure
| CONDUCTOR | Plain Copper |
| STRANDING | Class 5 |
| INSULATION | XLPE |
| ARMOUR | Steel Wire Armour |
| OUTERSHEATH | LSZH |
| OUTERSHEATH COLOUR | Black |
| RATED VOLTAGE | 0.6/1kV |
| CORE IDENTIFICATION | Element A (CAT 6A F/FTP) Blue, White Orange, White Green, White Brown, White Element B (Power Cable) Blue, Brown and Green/Yellow |
| MINIMUM BENDING RADIUS | 10 x Overall Diameter |
| OPERATING TEMPERATURE | Flex/installation Temperature: -5°C to +65°C Static/workinTemperature: -20°C to +80°C |
| STANDARDS | EIA-TIA 568, IEC 11801, IEC 61156, EN 50173, EN 50288-10-1, IEC 60502-1, IEC 60332-3-24, IEC 60332-1-2 |
EV POWER + DATA LSZH Specification Data
| Number of cores | Nominal cross sectional area of conductor | Element A diameter | Diameter under armour | Approx overall diameter | Weight | Element B Max. Conductor Resistance |
| 3 | 4 | 8.3 | 15.3 | 20.1 | 710 | 4.95 Ω/km |
| 3 | 6 | 8.3 | 16.3 | 21.1 | 810 | 3.30 Ω/km |
