(N)SSHÖU Cable

Cable-unis' mining cable portfolio includes (N)SSHÖU O/J, (N)SSHÖU 3E, and (N)SSHÖU 3E+ST cable, all with a voltage rating of 600/1000V.
The cable can also be written and referenced as (N)SSHOEU. Cable-unis' range of (N)SSHÖU cables are available with control conductors and individual core screens on request.

Commonly used in the mining industry as tough flexible rubber power connections, the (N)SSHÖU cable are heavy-duty drilling and tunnelling equipment cables with a flame retardant, UV resistant outer sheath designed to withstand abrasions, cuts, tears and oils & greases. These cables can be used as power supply where high levels of mechanical stress and abrasion are expected.

(N)SSHÖU cables can be submerged in water, including salt water, oily and sewage-contaminated water, up to a depth of 100m. They can be used in dry, damp, wet and hazardous environments.

This range has a temperature rating of -25℃ to +80℃ when flexed and -40oC to +80oC when used in a fixed installation. Like many other mining power cables, the (N)SHÖU, (N)SSHÖU and (N)SSCHÖU cables are manufactured generally to German standard VDE0250 part 812.

Construction Table


	(N)SSHÖU O/J, (N)SSHÖU 3E, (N)SSHÖU 3E + ST 0.6/1KV CABLE
VOLTAGE	0.6/1kV
CONDUCTOR	Class 5 Flexible Stranded Tinned Copper
INSULATION	Rubber Compound
INDIVIDUAL CORE SCREEN	Up to 10mm2: Copper Braid Above 16mm2: Copper Wires
CONTROL CONDUCTORS	Class 5 Flexible Stranded Tinned Copper
INNER SHEATH	Rubber Compound
OUTER SHEATH	Rubber

For further advice on the most appropriate applications for (N)SSHÖU cable and detailed technical specifications on the range including control conductors and individual core screen, please see our datasheet or speak to our technical experts.
