10KA Gapless Polymer Type Lightning Arrester

PRODUCT DESCRIPTIONZnO lightning arrester is one kind most world advanced over-voltage protector at present, due to its core components of resistance applying Z

PRODUCT DESCRIPTION

ZnO lightning arrester is one kind most world advanced over-voltage protector at present, due to its core components of resistance applying ZnO and other metal oxide to make of, comparing with traditional carborundum arrester, it improves greatly V-A characteristics of resistance, increases the getting trough ability of resistance, there by it brings fundamental change to features of arrester.
Under normal working voltage, the current passing arrester only A class, when bearing over voltage, the escellent non-linear V-A features of arrester would make effect, the current passing through the arrester increase high to thousands of Ampere instant, the arrester is under getting through state, to release over-voltage energy, therefore it effective limits the damage to power transmission equipments due to over voltage.


PRODUCT PARAMETER

Model Number MOA Rated voltage (KVrms) MCOV KV(rms) Current impulse Residual Voltage 2ms Rectangular current impulse withstand A(crest) 4/10μs high current impulse withstand KA(crest)
1/4μsLightning current impulse KV(crest) 8/20μs Lightning current impulse KV(crest) 30/60μs Switching current impulse KV(crest)
YH10W-3 3 2.55 11.3 9 8.9 150 65
YH10W-6 6 5.1 22.6 18 16.8 150 65
YH10W-9 9 7.65 33.7 27 23.8 150 65
YH10W-10 10 8.4 36 30 23 150 65
YH10W-11 11 9.4 40 33 30 150 65
YH10W-12 12 10.2 42.2 36 27 150 65
YH10W-15 15 12.7 51 45 38.5 150 65
YH10W-18 18 15.3 61.5 54 46.2 150 65
YH10W-21 21 17 71.8 63 54.2 150 65
YH10W-24 24 19.5 82 72 62 150 65
YH10W-27 27 22 92 81 69.8 150 65
YH10W-30 30 24.4 102 90 79 150 65
YH10W-33 33 27.5 112 99 86.7 150 65
YH10W-36 36 29 123 108 92.4 150 65
